Regulators

Swagelok KPR1DRF412A20000

SKU: 8028

In Stock

Used
Sourced from working environment

Price on request

Prices exclude VAT. Contact us for bulk pricing or custom configurations.

Important: All warranties are our own warranties and do not cover factory or manufacturer warranties.

Warranty Periods by Condition

New 12 months

Refurbished DOA

Used DOA

We are not an authorized distributor, representative, or affiliate of any manufacturer or brand listed on this website

Specifications

Attribute	Value
Body Material	316 Stainless Steel
Cleaning Process	Standard Cleaning and Packaging (SC-10)
Flow Coefficient	0.06 Cv
Handle	Green Knob Handle
Maximum Inlet Pressure	3600 psig (248 bar)
Maximum Temperature, °F (°C)	176 (80)
Port Configuration	F
Ports	1/4 in. Female NPT
Pressure Control Range	0 to 25 psig (1.7 bar)
Sensing Mechanism	X750 Diaphragm
